JINGLE GU15A | 15KG扬声器墙壁挂件

Professional speaker wall mount stand
GU15A
Speaker wall mount stand
ROBUST AND VERSATILE
CORROSION PROTECTION
WILL PROVIDE A VARIETY OF FORMS OF MOUNTING

Using in:≤15KG Speakers, lights, other wall mounted equipment

Installation method: wall

Adjustable angle: horizontal and vertical

Excellent GU15 multi-function speaker stands system

With the development of the Gabriel Engineering Department, the GU15 will have more new components to be launched and the base components will be composed of more different mounting styles. It can adjust the optimal inclination angle and fully display the advantages of your product.

Feature

One-mounted installation, freely adjustable, easy to flip, perfect design for a variety of mounting. The GU15 is more than a speaker stand, it is also a basic component of a multi-functional stand system.

The angle of depression adjustment angle: ±90°, horizontal rotation ±90°, to meet different angles. Gold ratio: 90mm away from the wall. Wire hiding: Intimate design avoids the wire slot wall spacing: 60MM, hide the connecting line, make the line neat and orderly, keep it clean and beautiful.

This series is composed of GU15A, GU15B, GU15C, GU15D.
To learn more about GU15, please click on the image link on the right.

GU15A

Technical Parameters		GU15A
The biggest bearing Horizontally Angle Vertical Angle Dimensions Maximum distance Accessories Net weight (1 Pcs) Material Colour Size of the packing Gross weight Using in	: : : : : : : : : : :	≤15 Kg -90°~+90° -90°~+90° 76 x 100 x 90 mm(WxHxD) 90 mm ● 0.31Kg 304 stainless steel Black 135 x 135 x 62 mm 0.8Kg Speakers \ Lighting \Hardware
